Belimo AFB24-SR Spring Return Actuator, 24V

These Belimo Actuators provide fail safe application and positive close off on air tight dampers. This specific series provides 95° of rotation and is provided with a graduated position indicator showing 0° to 95°. The AFB24-SR uses a brushless DC motor which is controlled by an Application Specific Integrated Circuit (ASIC) and a microprocessor.

Belimo AFB24-SR Features:

• Spring Return Modulating, 24Vac
• 2-10 Vdc
• 5.5 W Power Consumption Running
• 3 W Power Consumption in Rest
• 8.5 VA Transformer
• 180 in-lb Torque Motor
• Mechanical Position Indication
