Belimo NFX24-SR Damper Actuator, 24V

The Belimo NFX24-SR  is a customizable damper actuator. Used for on-off, fail-safe control of dampers in HVAC systems.

Belimo NFX24-SR Features:

• 24V AC/DC, 50/60 HZ
• 2-10Vdc Feedback Signal
• 4-20mA Operating Range
• 18 AWG Appliance Cable, 3 ft / 10 ft / or 16 ft available - with or without 1/2" NPT Conduit Connector
• 90 in-lb Torque
• 95 s Running Time
• Angle of Rotation: 95 Deg
• 3.5 Watt Power Consumption
• 2.5 Watt Rest Power Consumption
• 6 VA Transformer Sizing
• 2-10 V Operating Range
• 4-20mA with resistor
• IP54, NEMA 2

Technical Literature:

Belimo NFX24-SR Technical Data Sheet
