Warrick 3E3A Liquid Level Sensor, 3 Probe, 2" NPT

The Warrack Series 3E fittings hold 1 to 7 probes and are designed to operate at atmospheric pressure. The assembly mounts with external pipe threading atop open tanks or closed vessels. Series 3E fittings require the use of 3R rigid or 3W wire suspended electrodes.

Applications Include:

• Open Tanks
• Closed Vessels
• Water
• Diluted Corrosive Liquids

PLEASE NOTE: This does not include the level probes. Level probes are sold separately

Item is Built to Order

• Type of Connection: 2" NPT female
• Probes: 2 thru 3
• Terminal Housing: Die cast aluminum, epoxy coated
• Body Material: Cast iron
• Pressure/Temperature: 125 psig @ 353°F (cast iron); 250 psig @ 406°F (brass, 316 stainless steel)
• Approvals: UL File #MP2489, Vol. 1 Sec. 1, CSA; FM
• Conduit size: 3/4" NPT
