Belimo NMB24-MFT Damper Actuator, 24V

This series actuator is used for proportional modulation of dampers in HVAC applications.

Belimo NMB24-MFT Features:

• Non Fail-Safe Actuator
• MFT/Programmable Control Type
• 24V AC/DC, 50/60Hz
• 2-10Vdc Feedback Signal
• 4-20mA Operating Range
• 18 GA Appliance Cable with 1/2" Conduit Connector, 3ft length, for Electrical Connection
• 90 in-lb Torque
• Mechanically, 30-65mm Stoke Position Indication
• External Push Button Manual Override
• 3.5 Watt Power Consumption
• 1.3 Watt Rest Power Consumption
• 6 VA Transformer Sizing
• IP54, NEMA 2

Technical Literature:

Belimo NMB24-MFT Actuator Literature
