Honeywell S87J1026 Spark Module 11-second, Single rod

Provide electronic control of direct spark ignition systems used on gas fire furnaces, boilers, and other heating appliances.

Honeywell S87J1026 Features:

• Internal High Voltage Spark Generator Ignition source
• Natural or LP Gas
• 30 second minimum Prepurge
• 24 Vac for electrical ratings
• -40 to 175 deg F ambient temperature range
• Controls ignition sequence and gas control operation
• Generate high voltage potential for main burner ignition
• 5-1/4" high x 4-1/16" wide x 1-15/16" long
• Features:

  • Control ignition sequence and gas control operation.
  • Generate high voltage potential for main burner ignition.
  • Lockout after one trial for ignition if main burner fails to ignite.
  • Reset from thermostat after lockout.
  • Use modules (except S87C) with any combination gas control designed for direct spark applications and rated 2.0A or less.
  Specifications:

  • Temperature Range - -40 F to +175 F
  • Dimensions - 5 1/4 in. high x 4 1/16 in. wide x 1 15/16 in. long
  • Frequency - 60 Hz

  Technical Information:

  https://customer.resideo.com/resources/Techlit/Tec...
