Honeywell VC7936ZZ11-529 VC Actuator 24Vac, 2 to 10 Vdc

Used with control central heating and/or cooling systems, fan coil systems, radiators and convectors. Depending on the model selected, it can be controlled by either a low or line voltage SPST or SPDT or floating or modulating controller.

Features:

• Used with Two-way or Three-way valves
• Double insulated actuator
• Five foot plenum-rated cable
• Quick and easy replacement of moving parts
• Actuator head installation does not require draining the system
• Includes flexible conduit adapter
• Plastic housing material
• Direct coupled mounting
• 24 Vac supply voltage
• 32 F to 150 F ambient temperature range
• 5 to 95% RH, non-condensing operating humidity range
• Self-Alignment shaft adapter type
• Lever for manual operation
• 24 V Pulse width modulation; On/Off; 24 Vac Floating; 2 to 10 Vdc Control Signal
• 2.8" high x 3.7" wide x 2.7" deep
