Honeywell W7080A1016 Multizone Load Analyzer

Controls heating, cooling and space demand oriented economizer operation in the Honeywell Electronic Dual Set point Multizone control system.

Features:

• Controls 3 stages of on/off heating, modulated heating, modulated economizer, 3 stages of on/off cooling and modulated cooling.
• Responds to highest heating and cooling demand signal from up to 12 T7080 Zone Thermostat/Transmitters.
• Analyzer is short-circuit protected source of 24 Vdc power for zone thermostat/transmitter, sensor and W7081A Limit Controller Package.
• Switches all stages off when power is interrupted; switches stages on when power is restored.
• Compressor turn-on time delays must be incorporated for each compressor.
• No adjustment or calibrations required.
• Night setback and cooling shutdown for individual or all zones by addition of time-clock.
• Mounts with 4 No. 8 Screws (not provided) through holes in base.
• 1/4" Quick-connect male terminals for electrical connections
• 24 Vdc voltage
• -40 F to 150 F operating temperature range
• 6-1/4" high x 4-1/8" wide x 2-5/16" deep
