Honeywell W7762B1027 Excel 10 Hydronic Controller

W7762 Hydronic controllers cover a wide range of control applications including radiators, induction units, fan coil units with manual switching, and simple VAV. They are suitable for unit/wall mounting as stanalone or part of a LonWorks bus network.

Features:

• High efficiency, low cost Heat/Cool valve application solution
• Model with integrated or remote wall module LonWorks Open protocol: flexibility now and for the future
• Direct connection of thermal actuators
• Wide range of supported valves and actuators
• 2-pipe, 4-pipe, 3 Heat / 3 Cool application size
• 0.5 VA maximum (no load) power consumption
• 24 Vac
• 32 F to 158 F setpoint temperature range
• Output Type: Floating; Pulse Width Modulation; Staged On/Off; Multi-stage Electric
• 2 Inputs and 2 control outputs
• 5 to 95% RH, non-condensing operating humidity range
• 3-5/32" high x 4-11/32" wide x 1-21/32" deep
