Honeywell C7150B1004 Mixed Air Temp Sensor

This Honeywell product is used for duct or discharge dire with a 3000 ohms @ 25C NTC sensor. For use with Honeywell economizer logic modules and W973 and M7415 to proportion outdoor and return air dampers in economizer systems. Uses thermistor sensing element in ventilation duct systems. Negative temperature coefficient (NTC) causes resistance to decrease as sampled air temperature increases. Resistance change used as in input to control W973 and M7415. Requires no settings or calibration. This product mounts on duct surface with four screws (not supplied).

Features:

• Duct or Discharge Air Temperature Sensor
• 3000 ohms @ 25C NCT
• 1/4" Quick-Connect Terminals
• 40 to 110 Degree F Operating Temperature Range
• Black Color
• 250 Deg F Ambient Temperature Range
• Mount on mounting bracket (not included) inside the mixed air or discharge air duct
• 2" High x 2-1/2" Wide x 3/4" Deep

See technical tab for literature on part # C7150B1004
