SealMaster MPD-19 Medium Duty Pillow Block Bearing, 1-3/16" Shaft, Set Screw Ball Bearing

The SealMaster MPD-19 Medium Duty Pillow Block Bearing is a medium duty set screw ball bearing.

SealMaster MPD-19 CXU Features:

• 1-3/16" Shaft
• Ball Rolling Element
• Standard Felt Seal
• Solid Housing Base
• 250° Max Operating Temperature
• Cast Iron, Two-Bolt Block

Please see Technical Tab for Literature and Drawing

• "A" Dim: 1-7/8"
• "B" Dim: 6-7/8"
• "C" Min: 4-1/2"
• "C" Max: 5-1/2"
• "D" Dim: 2-1/4"
• "G" Dim: 11/16"
• "H" Dim: 3-13/16"
• "J" Dim: 2"
• "K" Dim: 1"
• Bolt Size: 1/2"
